HESS

Household Energy Storage System
Global Leading Green Energy Solution Provider.

All In One Lead Carbon ESS

Tianneng lead-carbon energy storage machine products TNAiO-1022-AL0210S2, TNAiO-1522-AL0210S1, TNAiO-2522-AL0315S1 is a household energy storage products, integrated design, Lead-acid/Lead carbon two battery types optional, intelligent digital energy storage equipment, suitable for sunny, power unstable areas, the product has a very cost-effective, easy to install and use, very suitable for household backup power use, welcome global partners to purchase!

Product Feature

Tianneng household energy storage products have excellent performance, and consumers have a good sense of experience.
All in one design
Integrated design of built-in MPPT and battery.Diversified batteries are available: lead-acid/lead-carbon.
Rich interface
Two 5V/3A, two 12V/2A, which can meet the power supply requirements of different DC devices.Type C 5V/3A and Type C-100W special interface for high-power equipment.
Automatic control
Fully automatic control and management function, large-size dot-matrix LCD display, rich user setting interface, real-time monitoring system parameters.
Plug And Play
The on-site operation is simple, the installation is convenient, and the labor cost is effectively saved.


Technical Atlas


Product Specification

ModuleTNAiO-1022-AL0210S2TNAiO-1522-AL0210S1TNAiO–2522-AL0315S1
Rated Utility work voltage220VAC
Utility work voltage range176VAC~285VAC

Utility input frequency range

45Hz-65Hz

Max.Utility work current

(Charging+Bypass

2.2A for charging+4.5A

for bypass@220VA

2.8A for charging+6.8A

for bypass@220VAC

3.5A for charging+11.4A

for bypass@220VAC

Utility transfer timeUtility bypass to lnverter output:<10ms Inverter output to Utility bypass: Oms
AC input overload relayYES
Rated output power(@25°C)1000W1500W2500W
Surge output power(5s)1500W2000W4000W
Rated output voltage220VAC土3%
Rated output frequency50Hz/60Hz士0.2%
Output wavePure sine wave
Output distortion THD≤3%(Resistive load)
Output soft startHAVE
